How to choose the right tool for machining on a Mazak QT250 CNC lathe?
Selection of tools suitable for Mazak QT250 CNC lathe machining, need to consider a number of factors, the following is the specific selection method:
1, according to the processing material
- **Steel parts**: processing of general hardness of steel parts, you can choose carbide tools, such as YW1, YW2 and other grades of inserts, with better wear resistance and cutting performance. For higher hardness steel parts, you can use cobalt-containing high-speed steel tools or coated carbide tools, coated tools can improve the hardness, wear resistance and lubricity of the tool, such as TiN coated tools.
- **Cast iron parts**: when processing cast iron parts, tungsten and cobalt carbide tools can be used, such as YG6, YG8 and so on. These tools have better impact resistance and wear resistance, and can adapt to the intermittent cutting of cast iron materials.
- **Non-ferrous metals**: Processing non-ferrous metals such as aluminum, copper, etc., diamond tools or PCD tools can be used, which have extremely high hardness and wear resistance, and can achieve high-precision and high-efficiency cutting, and obtain good surface quality. You can also use tungsten and cobalt carbide tools, cutting speed can be increased appropriately.
2、According to the process requirements
- ** Roughing **: roughing, in order to improve machining efficiency, should choose a large feed of the tool, such as indexable milling cutter, large size of the turning tool, etc.. The cutting edge of the tool should have strong impact resistance and wear resistance, and can choose carbide tools, and can use a larger tip arc radius to increase the strength of the tool.
- **Finishing**: Finishing requires tools with high precision and surface quality to ensure the dimensional accuracy and surface roughness of the processed parts. For example, high-precision fine-tuning tools can be used for fine turning, and precision boring tools can be used for boring. Cutting edge of the tool should be sharp to reduce the cutting force and cutting heat, to avoid the production of chip tumors and burrs, can choose PCD tools, CBN tools or high-precision carbide tools.
3、According to the performance of the machine tool
- **RPM**: The maximum speed of Mazak QT250 CNC lathe is high, and the speed range of the tool should be considered when selecting the tool. For high-speed cutting, should choose a good dynamic balance, can adapt to the high speed of the tool, such as the use of HSK shank tool, has a better rigidity and accuracy retention, can adapt to the requirements of high-speed cutting.
- **Power**: If the machine tool power is large, you can choose a large size, large feed tool, give full play to the power advantage of the machine tool, improve processing efficiency. For some complex machining, such as multi-axis linkage machining, you also need to consider the tool interference problem, select the appropriate tool shape and length, to avoid collision between the tool and the workpiece or fixture.
4, according to the type of machining
- **Turning**: external turning can choose different types of external turning tools, such as offset, sharp, arc knife, etc., according to the processing requirements to choose the appropriate insert material and type. Bore turning requires the selection of bore turning tools, according to the diameter, depth and accuracy requirements of the bore to select the size and accuracy level of the tool.
- **Milling**: plane milling can choose end milling cutter, face milling cutter, etc.; contour milling can choose end milling cutter, ball end milling cutter, etc.. For some complex surface milling, you may need to use five-axis linkage milling machine and the corresponding tool, such as impeller processing can use a special impeller milling cutter.
- **Drilling**: Select the appropriate drill bit according to the diameter, depth and accuracy requirements of the drill, such as ordinary twist drills, center drills, deep hole drills and so on. For high-precision drilling, reamers can also be selected for reaming processing to improve the dimensional accuracy and surface quality of the holes.
5、 According to cost and efficiency
- **Cost**: Under the premise of meeting the processing requirements, the cost of the tool should be considered. Generally speaking, the price of coated tools is relatively high, but long service life, the overall cost may be more cost-effective; and ordinary carbide tools are relatively low in price, suitable for some of the processing occasions that do not require high tool life.
- **EFFICIENCY**: Selection of tools to consider its cutting efficiency, such as indexable tools due to the fact that they can continue to be used by replacing the inserts, reducing the tool replacement time and improving the processing efficiency. Some new tool materials and tool structure, such as high-efficiency milling cutters, new drills, etc., can increase the cutting speed and feed, thus shortening the processing time and improving productivity.
