What makes and models of slow-wire equipment are recommended?
Here are some recommended brands and models of slow-wire equipment:
### Fanuc
- **α-C400iB**: Table travel is 400mm×300mm, Z-axis travel is 255mm, workpiece size can be processed 730mm×630mm×250mm, using wire diameter 0.1-0.3mm, suitable for processing small and medium-sized precision parts, the equipment has high precision, automatic threading function is powerful, it can complete the automatic threading of 0.10 fine wire in 10 seconds, and it has good processing stability and can effectively guarantee the processing precision and surface quality. The machine has high precision and powerful automatic threading function, which can finish 0.10 fine wire threading automatically within 10 seconds.
- **α-C600iB**: Stroke 600mm x 400mm, Z-axis stroke 310mm, workpiece size 1050mm x 820mm x 300mm, load capacity up to 1000kg, suitable for medium-sized molds and parts machining, high cutting efficiency to meet the needs of mass production, and its high-precision positioning and repetitive positioning system, which ensures the consistency of the machining dimensions. .
- **α-C800iB**: Table travel 800mm×600mm, Z-axis travel 310mm, workpiece size up to 1250mm×1020mm×300mm, mainly used for large molds and large parts machining, with strong cutting capacity and stability, can adapt to complex shapes and high-precision requirements of the machining task.
### West
- **M35HP**: the movement of each axis is 350mm×300mm×230mm, the maximum workpiece size is 700mm×630mm×220mm, the maximum workpiece weight is 350kg, the diameter of the wire electrode is 0.07-0.3mm, it is suitable for small precision parts machining, it has the characteristics of high precision and high efficiency, and its pitch machining accuracy can reach ±1um, it can It has high precision and high efficiency, and its pitch machining precision can reach ±1um, which can meet the production of parts with extremely high requirements for machining precision.
- **M50B**: table stroke 500mm x 350mm, maximum cutting thickness 300mm, surface roughness 0.2um, electrode wire diameter range 0.1-0.3mm, maximum load-bearing capacity of 800Kg, taper ± 10 ° / plate thickness of 300mm, can be processed for larger sizes and weights of the parts, while maintaining a high degree of machining accuracy and surface quality, and can adapt to the needs of diversified precision machining. It can meet the diversified demands of precision machining.
### Sardick
- **AQ325L**: with high cutting accuracy and surface quality, it is suitable for processing small and medium-sized precision molds and parts, with good stability and long time stable operation, which can effectively reduce the production interruption caused by equipment failure and improve the production efficiency.
- **AQ400LS**: excellent processing accuracy and stability, can achieve high precision cutting processing, suitable for the processing of parts with strict requirements for dimensional accuracy and surface roughness, such as precision molds, aerospace parts and so on.
- **ALN400**: balanced performance in cutting efficiency and precision, can meet the general demand for precision parts processing, has a good cost performance, suitable for small and medium-sized enterprises and processing workshop selection.
### Charmilles
- **CUT P 350 Pro**: The standard configuration of wire guide nozzle diameter is 0.10-0.30mm, the maximum cutting taper is 30°/100mm, the maximum moving speed of X and Y axes is 3m/min, and the threadable height is 250mm, which is suitable for machining small precision parts with high precision and high efficiency, and its advanced electronic control system can provide higher machining precision and stability.
- **CUT P 550 Pro**: similar performance to CUT P 350 Pro, but the processing size range is larger, can meet the processing needs of medium-sized parts, with higher cutting accuracy and surface quality, can effectively improve processing efficiency and product quality.
- **CUT P 800 Pro**: can process parts of larger sizes, the maximum cutting taper and threading height and other parameters are further improved, suitable for large molds and parts processing, its stable cutting performance and high-precision machining capabilities to ensure that the processing of large parts precision and quality.
### Mitsubishi
- **FA20S**: suitable for processing small precision parts, with high processing accuracy and stability, high success rate of automatic threading, easy to operate, can effectively improve processing efficiency and reduce labor costs, suitable for small and medium-sized enterprises and processing workshops.
- **MV1200S**: Adopting sleeve linear motor drive and Opt Drive System, it improves machining precision and response speed, realizes high speed machining of micro-fine surfaces, greatly improves the success rate of automatic threading of electrode wires, and extends the corresponding range of bending rate from 3% to 10%, and greatly improves the success rate of threading of broken wires of thick plates, which is suitable for machining of parts with high requirements for machining precision and surface quality. This makes the machine suitable for processing parts with high demands for machining accuracy and surface quality.
- **DWC-200HA**: With excellent performance in precision and efficiency, it can meet the needs of medium and large-sized molds and parts processing, and its advanced drive system and control system can ensure the stability and precision of the processing process and improve productivity.
### Precision Presentation
- **V50 water jet type**: large workpiece size 950mm x 650mm x 255mm, XY-axis travel 500mm x 300mm, UV-axis travel 120mm x 120mm, Z-axis travel 260mm, using wire diameter 0.15-0.3mm, adopting stabilized arc-inducing voltage circuit and electrolysis-free discharging power supply system, which can maintain cutting stability and increase speed, and at the same time The RTS discharge circuit can effectively monitor the discharge state, reduce the phenomenon of broken wires, and improve the processing efficiency and precision.
