Introduction of Youjia NBP-1000A Vertical Machining Center
The following is a detailed introduction about Youjia NBP-1000A Vertical Machining Center:
1.Basic Parameters
- **Table**: table size 1150mm×600mm, table load 1000kg, T-slot size 18mm×5×100mm.
- **Travel**: X-axis travel 1000mm, Y-axis travel 600mm or 610mm, Z-axis travel 600mm.
- **Spindle**: Distance from spindle nose to table surface 110-710mm, distance from spindle center to column track surface 660mm, spindle speed up to 10000rpm, spindle diameter 70mm, main motor power 7.5-11kw.
- **Other**: The external dimension of the machine tool is 3180mm×2185mm×2900mm, and the weight of the machine tool is 7000kg.
- **Structural design**.
- **Strong machine body**: made of high-strength cast iron with aging treatment, it has good stability and shock resistance, can withstand the impact generated by high-speed cutting and heavy-load machining, and safeguard the machining accuracy and surface quality.
- **Three-axis hard-rail design**: NBP-1000A adopts three-axis super-large span hard-rail design, the hard-rail is characterized by high rigidity, which can withstand large cutting force and is suitable for heavy cutting machining, and the hard-rail's good abrasion resistance ensures that the machine tool's accuracy can be maintained after long-term use.
- **A-type column**: A-type column bottom reinforcement design, this structural design can effectively improve the stability and rigidity of the column, reduce the deformation of the column in the machining process, so as to improve the machining accuracy.
- **Z-axis optimization**: Z-axis horse power is increased and brake mechanism is added, which can improve the rounding precision, and at the same time avoid the structural vibration problem caused by the general counterweight block, so that the Z-axis is smoother in the movement process, and the positioning is more accurate.
2.Performance features
- **High-precision positioning**: Positioning accuracy can reach ±0.005mm for X-axis, Y-axis and Z-axis, and the repeatability can reach ±0.003mm for X-axis, Y-axis and Z-axis, which can satisfy the demand of high-precision parts machining.
- **High-efficiency machining capacity**: Equipped with high-performance spindle motor and advanced transmission system, it can realize high-speed cutting and powerful cutting, greatly improving the machining efficiency. The automatic tool changer is quick to change tools and reduces auxiliary machining time. In addition, optional GF gear box is available to increase the machine torque and increase the machining range, which can really realize low-speed heavy cutting and high-speed fine cutting.
- **Rich Function Configuration**: Standardly equipped with workpiece measuring side device, chip conveyor or spiral chip removal, automatic tool length measuring device and breakage detector, spindle center water discharge system, etc.. It can also be equipped with automatic lubrication system, spindle nose air curtain chip prevention device, three-axis screw pre-drawing, rigid tapping, heat exchanger and so on according to the user's needs, which expands the machining range and process capability of the machine tool.
- **Stable and reliable operation**: Centralized automatic lubrication adopts Japan's “SHOWA” automatic lubrication system, which can lubricate the various moving parts of the machine tool at regular intervals and in quantitative terms, reducing the friction between the parts and improving the service life of the machine tool and its operational stability.
3. CNC system: usually can be configured with Mitsubishi, Siemens, Fanuc and other well-known brands of CNC systems, these CNC systems have easy operation, powerful functions, high stability, and can realize the programming and processing of complex parts.
4. Application areas: particularly suitable for machining, automotive parts, mold industry, engineering machinery, textile machinery, aerospace, non-ferrous metals, alloy materials, medium-sized wide-body molds and other fields, can be processed in a variety of flat, curved surfaces, holes system and other parts.
- **Price**: the price of a new machine tool is generally around 35-38 million yuan.
