Niles Cylindrical grinder

X*Z axis travel: 2300*1000mm

Grinding wheel diameter * width * internal diameter: 1000*320*160mm

Guideway: XZ full close loop hydrostatic pressure

Drive mode per shaft: XZ screw

Worktable size :2800*400mm

Worktable load: 1000kg

Grinding travel: 2500mm

Spindle transmission mode: full static mechanical motorized spindle

Grinding wheel resolution: 1082

Chip convey: magnetic

Dimension: 9500*3000*2900mm

Machining diameter: 650mm
