SHIGIYA GP-30B 150H Cylindrical grinder
[Product Information]:
- Inventory number：65333
- Brand：SHIGIYA
- Model：GP-30B 150H
- Origin："Japan
- Location：China
- Year：To be supplemented
- Create Time：2025-08-02
Specifications:
WorkWorktable rotation diameter :200mm
Grinding length of workWorktable :1500mm
grinding wheel size: external diameter 320-405mm
Thickness: 25-75mm
Internal diameter: 152.4mm
WorkWorktable rotation Angle :+7°, -1°
The rotation Angle of the workpiece headstock :+20°, -80°
spindle and tailstock through holes: Mohs 4
Its rotational diameter: 300mm
WorkWorktable width: 200mm
Maximum workpiece weight: 20kg
The maximum speed can reach: 2000m/min
