Makino U6 Wire cutting machine

three-axis travel: 650*450*420mm

U*V axis travel: ±75*±75mm

WorkWorktable size (square) : 910*710mm

WorkWorktable size (U type) : 910*710mm

Maximum workpiece size: 1000*800*400mm

Maximum page height: 455mm

Maximum workpiece weight: 1500kg

WorkWorktable height: 1000mm

Wire diameter: 0.1/0.15/0.2/0.25/0.3mm

Maximum taper: ±15°/100mm

machining  liquid capacity: 920L

Ion exchange resin: 20L

machining  fluid filter: 2/4

machine tool size: 2273*2908*2350mm

Floor area: 2700*4310mm

machine tool weight: 5200/5300kg
