NAGASE SGC 107 Surface grinder

three-axis travel: 1500*750*1000mm

Footage: 6000*5000*4000mm

grinding wheel size: (φ250-510) * (38*50) *φ127

Sand wheel shaft: 7.5

Distance from Worktable top to spindle center: 1000 mm

travel (horizontal, vertical: 1500*760

Minimum feed: 0.0001mm

WorkWorktable size :1000*700mm

Drive mode per shaft:

Y*Z axis: servo drive

X axis: servo hydraulic drive, controlled by glass scale

guideway mode: 3 axes static pressure

3 axes glass scale
