KENT KGS-615WM1 Grinding machines

Worktable size: 1500×600mm

X-axis travel: 1600mm

Y-axis travel: 660mm

Maximum distance from worktable surface to spindle center: 600mm

Maximum load: 800kg

T-slot size: 16×3mm×N

Worktable speed: 5-25m/min

Grinding wheel speed: 50Hz-1250rpm, 60HZ-1500rpm

Automatic feeding rate: 0.005-0.04mm

Machine dimension: 2400×5000×2600mm
