Aida NCS-250 (2) Punch / press

[Product Information]:

Capacity: 250tf

Slide stroke: 280mm

Strokes per minute(No load): 20-40spm

Die height: 550mm

Slide adjustment: 120mm

Slide area: 2100*700mm

Bolster area: 2400*920mm

Main power: 30kW

Required air pressure: 5kgf/cm²
