Mitsubishielectric EA8SM Spark eroder
[Product Information]:
- Inventory number：70422
- Brand：Mitsubishielectric
- Model：EA8SM
- Origin：Japan
- Location：China
- Year：
- Create Time：2023-02-09
Specifications:
Machine dimensions (length * width * height) 1530 * 2000 * 2105 [mm]
Machine weight 2000 [kg]
Travel (X * Y * Z) 300 * 250 * 250 [mm]
Distance between worktable and electrode mounting surface 150-400 [mm]
Spindle motor weight 25 [kg]
Work tank internal dimension (length*width*height) 800*520*300 [mm]
Adjustment range of the liquid level of the machining groove 85-250 [mm]
Worktable size (width * length) 500 * 350 [mm]
Workpiece machining size (length * width * height) 770 * 490 * 290 [mm]
Worktable load 550 [kg]
T-slot spacing 12-120 [mm]
