LK INTEGRA CMM

Brand and model : LK INTEGRA

Measuring travels:

X-axis 1000mm

Y-axis 700mm

Z-axis 600mm

Measurement accuracy (ISO10360-2) (temperature change within 4℃):

Allowable indication error of length measurement MPEe 1.90+L/350um

Allowable detection error MPEp (TP200/SP25) 2.8/2.5um

Scanning detection error MPETHP (SP25) 4.50um/59sec

3D speed 39m/min

3D acceleration 4800mm/sec2

Worktable load 822kg

Machine weight(approximate) 1330kg

Machine dimensions 1920mmx1463mmx2696mm
