DMG CTX510eco CNC turning lathe

[Product Information]:

Inventory number：80123
Brand：DMG
Model：CTX510eco
Origin：Germany
Location：China
Year：
Create Time：2022-12-01

Specifications:

With hydraulic center frame

Length :1150mm, Rotary diameter :465mm
Rotation range on the machine surface :680mm
Transmission range on X skateboard :465mm
XZ axis ball screw drive D*P:40*10mm
XZ feeding force :7.5kn
XZC1 axis fast moving speed :30/30/100m/min
Chuck diameter :250mm
Spindle hole diameter :103mm
Spindle power :22/33kw
Bar through hole :76mm
Turning diameter :465mm
XZ axis travel :300*1050mm
