KYORI ANEX-60II High speed punch

Stamping capacity: 600KN
travel length: 25mm
Mold height: 300mm
travel per minute: 100-750spm
Slider size: 1100*600mm
Slider adjustment range: 80mm
Pressurization capacity: 600 kN
Impulse rate (SPM) : 100 to 750 beats per minute
travel length: 25mm
Closed mold height: 300mm
Slider adjustment range: 80mm
Mold and feeding specifications
Worktable size: 1100mm (left-right) × 600mm (front and back)
Feeding line height: minimum 70mm/maximum 130mm (adjusWorktable height, suiWorktable for different molds)
Feeding length: 0-80 mm
Maximum material width: 80mm
Power and auxiliary CNC Systems
Main motor power: 22 kW × 4 (High-power servo drive, ensuring torque and stability  for high-frequency stamping)
Air pressure used: 0.49 MPa
