MAZAK INTEGREX e‑650HS II Turn Mill Machining Centre

CNC System: MAZATROL Matrix
Maximum Swing diameter: φ920 mm
Maximum machining diameter: φ920 mm
Spindle through-hole diameter: φ170 mm
Maximum spindle speed: 1600 rpm
Spindle motor power: 45/37 kW
X-axis travel: 1025 mm
Y-axis travel: ±325 mm (650 mm)
B-axis travel: -30° to +210°
C-axis rotation: 360°
B-axis indexing accuracy: 0.0001°
C-axis indexing accuracy: 0.0001°
Maximum milling spindle speed: 10,000 rpm
Milling spindle tool holder: No. 50
