Liebherr LMC600G Measuring equipment
[Product Information]:
- Inventory number：4812679
- Brand：Liebherr
- Model：LMC600G
- Origin：Germany
- Location：China
- Year：2025
- Create Time：2026-08-10
Specifications:
Maximum workpiece diameter: Φ600 mm
Minimum measurable module: 0.2 mm
Maximum measurable tooth width: 800 mm
Distance between centers: 900 mm
Maximum load capacity of rotary worktable: 400 kg
Helix angle range: < 90°
Axis Travel
X-axis travel: 500 mm
Y-axis travel: 320 mm
Z-axis travel: 800 mm
CNC Measurement System Configuration
Guideway type: Granite guideways
Bearing system: Air bearings
Rotary Worktable
High-precision rotary worktable:
Aerostatic bearing type / Hydrostatic type
Probe System
Renishaw high-precision scanning probes:
SP600
SP80H
Accuracy Standard
Accuracy grade:
Conforms to VDI/VDE 2612/13 Grade 1 accuracy standard
