Deyung TV-700S Tapping machine

X/Y/Z Axis Travel：700 × 400 × 350 mm
Worktable Size：700 × 420 mm
Maximum Load：300 kg
T-slot：14 × 3 × 125 mm
Spindle Speed：20,000 rpm
Spindle Type：Direct-drive
Spindle Taper：BT40
Spindle Power：To be confirmed
Rapid Traverse Rate：48 / 48 / 48 m/min
Cutting Feed Rate：1000 mm/min
Tool Magazine Capacity：24 tools (optional)
Maximum Tool Length：300 mm
Maximum Tool Weight：3 kg
Positioning Accuracy：±0.010 mm
Repeatability：±0.005 mm
CNC System：FANUC Oi-MF / Mitsubishi M80
Air Pressure：6 kg/cm² (subject to actual machine)
Power Requirement：30 kVA
Machine Weight：6.5 tons
Standard Configuration
General
Rigid tapping
Coolant cleaning gun
Air gun for worktable cleaning
Full enclosure guard
Spindle air purge system (dust-proof)
Anchor bolts and leveling pads
Electrical cabinet heat exchanger
Work light
Tool box
Transformer
Signal tower light
Automatic lubrication system
Chip tray and coolant tank
Operation & maintenance manuals
Tool Magazine System
2-arm tool magazine (TV series)
24-disc tool magazine (DV series)
M30 automatic power-off system (DV series)
Optional Configuration (DV Series)
Screw-type chip conveyor
Scraper-type chip conveyor
Spindle center coolant system (CTS)
Spindle ring coolant spray system
1000 rpm belt spindle
1500 rpm electric spindle
2000 rpm electric spindle
30-tool magazine upgrade
Spindle oil chiller
Four-axis CNC rotary table
Automatic door
Oil mist collector
Centrifugal coolant separator
Automatic tool length measurement system
