DJTOL Bi5-8HA Tool grinder

Three-Axis Travel (X/Y/Z): 460 × 330 × 170 mm
A-Axis: 360° continuous rotation (indexing head)
C-Axis: -40° to +180°
Maximum Tool Diameter: 120 mm
Maximum Tool Length: 180 mm
Tool Diameter Range: 1–20 mm
Effective Cutting Length: 150 mm
Spindle Power: 7.5 kW
Spindle Interface: HSK40E automatic clamping, spindle runout ≤ 0.002 mm
Spindle Speed: 500–6000 r/min (variable frequency control)
Grinding Wheel Size: Diameter 75–150 mm, bore 31.75 mm
Grinding Wheel Magazine: 8-position servo type, 10-second quick change
