TAIYO KOKI NVG-12T Grinding machines

Grindable hole diameter: 45- Φ 1200 mm

Grindable external diameter range: Max  Φ 1200 mm

Maximum grindable length (external diameter) : 500mm

The diameter of spindle: Φ1250mm

The height of the removable machining : 600mm

The weight that spindle workWorktable can bear: 2500KG

Inner frosted axle

Rotational speed: 2500-10000rpm

Use grinding wheel: Φ40-Φ250mm

taper: BT50

External frosted wheel axle

Rotational speed: 2400-3000rpm

Use grinding wheel: 355*65mm

Maximum operating speed: 2700m/min

spindle rotational speed: 5-100rpm

Machine weight: 17,000 kg

Mechanical Footage: 3810*4300*3600mm
