Makino D500 5 axis machining centre
[Product Information]:
- Inventory number：4465303
- Brand：Makino
- Model：D500
- Origin："Japan
- Location：China
- Year：To be supplemented
- Create Time：2025-10-26
Specifications:
WorkWorktable size: 400*400mm
X-axis travel: 550mm
Y-axis travel: 1000mm
Z-axis travel: 500mm
Axis A: +30°/-120°
C-axis: 360°
Spindle speed: 14,000 RPM
X-axis Fast moving rate: 48,000 mm/min
Y/ Z-axis Fast moving rate: 5000mm/min
X-axis Cutting rate: 32,000 mm/min
Cutting rate of Y/Z axis: 40,000 mm/min
Maximum workpiece size: 650*420mm
Load-Load: 350kg
magazine capacity: 60
Tool to Tool: 4.2 seconds
Maximum Tool diameter: 140mm
Maximum Tool weight: 8kg
