NAGASE SHSD-80 Grinding machines

three-axis travel: 500*160*265mm

A-axis travel: ±90°

Chuck size: 80*100mm

WorkWorktable size: 100*150mm

WorkWorktable load: 13KG

grinding wheel speed: 20,000 RPM

Grinding Footage (external diameter * width * Internal diameter) :

Standard: 180* (0~10) *φ40

Path: (φ75~100) *10*φ40

Grinding travel: 80*100mm

spindle drive method: static pressure

The chip removal method of spindle: magnetic attraction

Minimum feed rate: 0.0001

Desktop spindle center: 370

The smallest unit before and after: 0.0001

Minimum vertical unit: 0.0001

Grinding wheel shaft rotation: ±5°

guideway method: Hydrostatic guideway

Drive mode per axis: lead screw

Overall Footage: 2300*1400*1900mm
