Mikron MIKRON WF 54 CH CNC milling machine

Controller Heidenhain TNC 355

Worktable length 1200 mm

Workbench width 600 mm

Longitudinal stroke (x-axis) 710 mm

Transverse stroke (Y-axis) 630 mm

Vertical stroke (Z axis) 500 mm

Spindle speed

Stepless speed change

Level from 10 rpm

Up to 6300 rpm

Vertical from 10 rpm

Up to 6300 rpm

Change knife

Number of tools 40

Shaft end ISO

feed

Stepless speed change

Longitudinal from 2 mm / min

Up to 4000 mm / min

Transverse from 2 mm / min

Up to 4000 mm / min

Vertical from 2 mm / min

Up to 4000 mm / min
