OKUMA&HOWA V80R CNC vertical lathe

CNC CNC System: FANUC 18T

Maximum rotation diameter: 1000mm

chuck  diameter: 610mm

Maximum machining  diameter: 800mm

Maximum machining  length: 840mm

Maximum workpiece mass: 800kg

XZ travel: 465*840mm

spindle rotational speed: 13-1250rpm

spindle nose shape: A2-11

The Internal diameter of spindle bearing: 200mm

The diameter of spindle through hole: 110mm

Blade stage form: V12

spindle motor power: AC30/22KW

Mechanical mass: 11,500 kg
