KITAMURA Mycenter- 3XH Vertical Machining centre

CNC CNC System: Mitsubishi M-750V

X*Y*Z axis travel: 760*455*460mm

WorkWorktable size: 410*900nm

Maximum load: 500kg

Spindle speed: 40-15000rpm

spindle taper: NST.NO.40

spindle motor power: 15kw

spindle torque: 95.5Nm

Fast feed rate: 50000mm/min

Chip feed rate: 0-36000mm/min

tools magazine :30

Distance from workWorktable to spindle nose: 110*570mm

machine tool weight: 5740kg

Footage: 2235*2370*2882.4mm
