Makino v56i Vertical Machining centre

three-axis travel: 900*550*450mm

Distance from top of Worktable to end face of spindle: 150-600mm

WorkWorktable size: 1050*550mm

Maximum workpiece size: 1050*720*450mm

Maximum load: 800kg

Spindle speed: 20000rpm

power: 18.5/15kw

Torque: 95.5/63.7N.m

Tool holder model: BT40

Bearing Internal diameter: 80mm

Fast moving rate: 20000mm/min

Cutting rate: 1-20000mm/min

magazine capacity: 15

Maximum Tool diameter: 80mm

Maximum Tool length: 300mm

Maximum Tool weight: 8kg

Footage: 3470*3110*2925mm
