HURCO VM20i Machining centre

X axis travel: 1016mm

Y-axis travel: 508mm

Z-axis travel: 508mm

Distance from spindle nose to workWorktable: 102-610mm

WorkWorktable size: 1168*508mm

工作台最大负荷：909kg

spindle maximum speed: 10000rpm

spindle power: 15/11kw

主轴扭矩：102/74N.m

magazine capacity: 20

spindle taper: BBT40

最大刀具直径：89/127mm

Maximum Tool length: 250mm

Maximum Tool weight: 7kg

Tool changing time: 2.5s

Fast feed rate: 24m/min

Positioning precision: 0.01mm

Repeat Positioning precision: 0.005mm

Footage: 2722*2859*2542mm

Machine weight: 4108kg
