Reishauer RZ400 Grinding machines

Maximum grinding wheel diameter: 400mm

gear width: 300mm

Maximum module: 8

Number of grinding teeth: 5-999

Pressure Angle: 14-30°

helix Angle: -45/+45°

workpiece maximum weight: 300KG

x axis: 490mm

Fast transverse X axis: 15m/min

Y-axis: 220mm

Fast transverse Y-axis: 5m/min

Z-axis: 300mm

Fast transverse Z-axis: 5m/min

Grinding wheel diameter: 205-300mm

grinding wheel maximum width: 125mm

Drilling diameter: 160H7mm

Startup times: 1-5

Total power required: 42kw

Machine weight: 12tons

Machine Footage: 7700x 5000 x 2900 mm
