Tongtai TMH-400 Horizontal Machining centre
[Product Information]:
- Inventory number：85915
- Brand：Tongtai
- Model：TMH-400
- Origin：Taiwan of China
- Location：China
- Year：To be added
- Create Time：2024-12-21
Specifications:
three-axis travel :510*510*510mm
WorkWorktable center to spindle nose :50~560mm
Worktable end face to spindle center :80~590mm
Height from WorkWorktable to ground :1150mm
WorkWorktable size :400mm
Maximum load :350kg
workpiece maximum size :510xH630mm(diameter/height)
Minimum split Angle :0.001deg
spindle taper: 7/24 Taper NT40
Maximum speed :8000rpm
Fast feed X/Y/Z:36/36/36m/min
Cutting feed X/Y/Z:1-10000mm/min
Tool storage :24pc
Footage :1700x3200x2690mm
Weight :6500kg
