SNK HF-4M Gantry machining centre
[Product Information]:
- Inventory number：85611
- Brand：SNK
- Model：HF-4M
- Origin：Japan
- Location：China
- Year：Ex-factory date to be added
- Create Time：2024-11-27
Specifications:
Effective distance between columns: 2500 mm
Worktable longitudinal: 7250 mm
Spindle head transverse: (3200 mm) +AACst.950 mm
Pull rod vertical: 1000 mm
Vertical beam: 1700 mm
Distance from worktable top to spindle nose: 2750 mm
Pallet working face (L x W) : 6000 x2000 mm
workpiece allowable mass: 20000 kg
Height from machine mounting surface to pallet top: 790 mm
Spindle speed range: 30-3000rpm
spindle nose: ISO 50
Internal diameter of spindle bearing: 120mm
grinding wheel cross section: 400x500
