Hartford PRO-3150 Gantry milling machine
[Product Information]:
- Inventory number：61287
- Brand：Hartford
- Model：PRO-3150
- Origin：中国台湾
- Location：China
- Year：2006
- Create Time：2024-06-19
Specifications:
Worktable size: 3100*1450mm
T-slot: 22*17*180mm
Maximum worktable load: 6000kg
Three axes travel: 3060*1560*780mm
Distance from spindle nose to worktable surface: 160-940mm
Spindle taper: ISO50S
Spindle speed: 6000rpm
Spindle motor power: 18.5/25kw
Cutting feed rate: 7000mm/min
Fast feed rate: 12000mm/min
Tool magazine: 32/40
Maximum tool weight: 15kg
Maximum tool size: 125*300mm
Tool holder: BT50
Positioning accuracy: ±0.015mm
Repositioning accuracy: ±0.005mm
Machine weight: 27000kg
Machine dimension: 10120*5640mm
