HURCO VM20i Machining centre

X-axis travel: 1016mm

Y-axis travel: 508mm

Z-axis travel: 508mm

Distance from spindle end face to worktable center: 102-610mm

Worktable size: 1168*508mm

Maximum worktable load: 909kg

Maximum spindle speed: 10000rpm

Spindle power: 15/11kw

Spindle torque: 102/74N.m

Tool magazine: 20

Spindle taper: BBT40

Maximum tool diameter: 89/127mm

Maximum tool length: 250mm

Maximum tool weight: 7kg

Tool changing time: 2.5s

Fast feed rate: 24m/min

Positioning accuracy: 0.01mm

Repositioning accuracy: 0.005mm

Machine dimension: 2722*2859*2542mm

Machine weight: 4108kg
