FEELER NBP-1000 Vertical Machining centre

Worktable size: 1150*600mm

X*Y*Z axis travel: 1000*600*600mm

Worktable load: 1000kg

Distance from spindle nose to worktable surface: 110-710mm

Distance from spindle center to column guideway surface: 660mm

Distance from worktable center to column guideway surface: 965mm

T-slot: 18*5*100mm

Spindle speed: 8000rpm

Spindle taper: BT40

Spindle diameter: 70mm

Main motor power: 7.5-11kw

Machine dimensions: 3180*2185*2900mm

Machine weight: 7000kg
