REISHAUER - RZ 820

Inventory number：812081

Brand：REISHAUER

Model：RZ 820

Origin：Switzerland

Location：China

Year：1998

Create Time：2026-05-25

Specifications:

Maximum machining diameter: 820 mm
Minimum machining diameter: 40 mm
Workpiece slide travel: 300 mm
Distance between centers: 865 (1185) mm
Maximum number of teeth: 600
Minimum number of teeth: 10
Maximum module: 7 (8) mm
Minimum module: 0.5 mm
Pressure angle range: 10°–30°
Helix angle range: ±30°
Maximum workpiece weight: 300 kg
Grinding wheel diameter: 400–280 mm
Grinding wheel width: 104 mm
Grinding wheel speed: 1100 / 2150 rpm
Gear feed per revolution: 0.6–3 mm/rev
